ADDRESSABLE SCANNING
Searches IDNet devices across addresses 0–255 and helps identify duplicated addresses.
SIMPLEXTESTING & PROGRAMMING
TRUESTART2
TSI2 INSTRUMENTPART NO. 0746-210
A portable installation and service instrument used to verify Simplex peripherals and field wiring before the fire alarm control panel is commissioned.
AVAILABLE BY ENQUIRYLead time confirmed on request
PRODUCT TYPEHandheld test instrument
CIRCUITSIDNet · IDNAC · IDC · NAC
SUPPLYQuotation on request
PRODUCT CAPABILITIESINSTALLATION & COMMISSIONING
FIND FAULTS.
VERIFY FASTER.
The TRUESTART2 helps technicians identify wiring, device addressing and circuit issues before connection to the main fire alarm control panel. It supports field verification across addressable and conventional circuits.
MULTIPLE CIRCUIT TYPES
Supports IDNet, IDNAC, conventional IDC, conventional NAC, earth fault and cross-talk testing.
DEVICE STATE CHECKS
Reads device type, address and selected operating information during field verification.
SAVED TEST RESULTS
Stores named test records for later review and transfer to compatible analysis software.
TECHNICAL
OVERVIEW.
- Model
- TRUESTART2 / TSI2
- Part number
- 0746-210
- Product type
- Portable handheld installation and service test instrument
- Circuits tested
- IDNet, IDNAC, cross-talk, conventional IDC, conventional NAC and earth fault
- IDNet search range
- Addresses 0–255
- Memory
- 60 internal named memory slots
- Power sources
- Lithium-ion battery, AC adapter or compatible 24 V DC source
- Approximate weight
- 5.1 lb / 2.3 kg
Product specifications are provided for initial reference and should be confirmed with Simple Axe before ordering.
View manufacturer information
